- Camera
- Lens2.8 mm to 12 mm
- Horizontal Field Of View108.4° to 32.6°
- Lens MountΦ14
- Day & NightIR cut filter
- SynchronizationInternal synchronization
- Angle AdjustmentPan: 0° to 355°, Tilt: 0° to 75°, Rotation: 0° to 355°
- Image Sensor2 MP CMOS image sensor
- Signal SystemPAL/NTSC
- Frame Rate
PAL: 4 MP@25fps, 1080p@25fps
NTSC: 4 MP@30fps, 1080p@30fps
- Resolution2560 (H) × 1440 (V)
- Min. Illumination0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
- Shutter Time1/25 (1/30) s to 1/50,000 s
- Menu
- AGCHigh/Medium/Low/Off
- Day/Night ModeAuto/Color/BW (Black and White)
- Backlight CompensationSupport
- DWDR (Digital Wide Dynamic Range)Support
- LanguageEnglish
- FunctionsBrightness, Sharpness, DNR, Mirror, Smart IR
- Interface
- Video Output1 HD analog output
- Switch ButtonTVI/AHD/CVI/CVBS
- General
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
- Power Supply12 VDC ± 15%
- Power ConsumptionMax. 4 W
- MaterialMetal
- IR RangeUp to 40 m
- DimensionsØ 143 mm × 106.7 mm ( Ø 5.62″ × 4.19″)
- 630 g (1.39 lb.)
- Ingress ProtectionIP66,IK10
