- Camera
- Image Sensor2 MP CMOS image sensor
- Max. Resolution1920 (H) × 1080 (V)
- Min. Illumination0.02 Lux@(F1.2, AGC ON), 0 Lux with IR
- Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Day & NightIR Cut Filter
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
- Lens
- Lens TypeFixed focal lens, 2.8 mm and 3.6 mm optional
- Focal Length & FOV
2.8 mm, horizontal FOV: 96.5°, vertical FOV: 48.9°, diagonal FOV: 120.5°
3.6 mm, horizontal FOV: 76.9°, vertical FOV: 40.6°, diagonal FOV: 92.0°
- Lens MountM12
- Illuminator
- Supplement Light TypeIR
- Supplement Light RangeUp to 20 m
- Image
- Image Parameters SwitchSTD/HIGH-SAT
- Image SettingsAGC;Brightness;Smart IR;Mirror;Sharpness
- Frame Rate
PAL: 1080p @ 25 fps
NTSC: 1080p @ 30 fps
- Day/Night ModeAuto/Color/BW (Black and White)
- Wide Dynamic Range (WDR)Digital WDR
- Image EnhancementDWDR;BLC
- Noise Reduction2D DNR
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- General
- Power12 VDC ±15%, Max. 2.1 W
- MaterialPlastic
- Dimension165 mm × 62 mm × 58 mm (6.50″ × 2.44″ × 2.28″)
- 400 g (0.88 lb.)
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
- Approval
- ProtectionIP66
