Product Model
- Product ModelDS-D5B75RB/A
Display
- Screen Size75 inch LED Backlight
- BacklightDLED
- Pixel Pitch0.143(H) × 0.430(V) mm
- Resolution3840 × 2160 @60 Hz
- Brightness350 cd/m²
- Color Depth10 bit
- Contrast Ratio1200：1（Typ.）
- Response Time6 ms
- Color Gamut90% NTSC（CIE1931）（Typ.）
- Refresh Rate60 Hz
- Viewing Angle178°(H)/178°(V)
Built-In System
- Operation SystemAndroid 8.0
- Processor4-core A73 × 2 + A53 × 2, 1.5 GHz
- Memory3 GB
- Built-In Storage32 GB
- NICBuilt-in 100 Mbps NIC, supporting routing
Touch
- TypeInfrared touch screen
- GlassAG smooth glass
- Touch Point20 point multi-touch
- Touch Response Time＜ 10 ms
- Touch Precision±1 mm (≥ 90% touching area)
- Touch CraftFull paste
Internal Function
- LoudspeakerBuilt-in 2 × 16 W loudspeaker
- BluetoothBuilt-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.0 and previous version.
Interface
- Video & Audio InputHDMI IN × 2，MAX 4 K @ 60 Hz, LINE IN × 1
- Video & Audio OutputHDMI OUT × 1，MAX 4K @ 60 Hz； LINE OUT × 1
- Control InterfaceRS-232 × 1
- Network InterfaceRJ45 (100Mbps ports) × 2
- Data Transmission Interface2 USB on front panel , 2 USB on rear panel
Power
- Power Consumption< 300 W (full load)
- Standby Consumption0.5 W
Working Environment
- Working Temperature0 ℃~40 ℃
- Working Humidity10%~90% RH
General
- PowerAC 100 V～240 V，50/60 Hz
- Product Dimensions1718× 1021 × 87.5 mm
- Package Dimensions (W × H × D)1927 x 1212 x 254mm
- Net Weight51.75 kg
- Gross Weight68.36 kg
